Product Description:
Vertical Lift Mechanism: The mast lifts vertically, providing stable elevation for workers and tools.
Self-Propelled: The unit can move on its own power, allowing easy repositioning without needing external assistance.
Compact Design: Typically compact, making them ideal for confined spaces.
Electric or Hydraulic Operation: They can be powered by electric motors or hydraulic systems.
Safe and Stable: Equipped with stabilizers or outriggers to ensure safety and stability at heights.
Platform Capacity: They can support varying capacities, depending on the model, generally suitable for one or two workers and their tools.
Ease of Operation: Often designed for ease of use, with straightforward controls for lifting and movement.
Features:
- Automatic brake system
- Emergency lowering system
- Emergency stop button
- Cylinder holding valve
- Intelligent onboard diagnostic system
- Non-marking tyres
- Automatic pothole protection
- Proportional controls
- Descent and tilt alarm
- Battery charger indicator
Technical Parameters:
| Model | AMWP6-6100 |
| Rated capacity | 159kg |
| Outreach working platform load | 114kg |
| Max. Working height | 8m |
| Max.Platform height | 6m |
| Overall lenght | 1.36m |
| Overall width | 0.82m |
| Overall height | 1.98m |
| Platform size | 1.3m*0.7m*1.1m |
| Platform outreach size | 0.51m |
| Max.ground clearance(stowed) | 0.1m |
| Max.ground clearance(raising) | 0.023m |
| Wheelbase | 1.04m |
| Min.turning radius(inner tyre) | 0.3m |
| Min.turning radus (outer tyre) | 1.8m |
| Lift motor/Drive motor | 1.3KW/0.5kw |
| Drive speed(stowed) | 4km/h |
| Drive speed (raising) | 1.1km/h |
| Lift/down speed | 52/53 sec |
| Battery | 2×12V/100Ah |
| Charge | 24v/15A |
| Max. Gradeability | 25% |
| Max.Working angle | 1.5° |
| Tyre | Φ305*100mm |
| Total weight | 1060kg |
Applications:
Aluminum alloy hydraulic lifting platform used high strength quality aluminum alloy materials,having advantages such as good-looking appearance,small size,light weight,steady moving,safety and so on.It's widely used in factories,hotels,restaurants,stations,theaters,exhibition centers,etc.And it's the best choice to maintain equipment,paint and decorate,change bulbs and electric devices and so on.
FAQ:
Q: What is the brand name of this electric lifting platform?
A: The brand name of this electric lifting platform is Eternalwin.
Q: What is the model number of this electric lifting platform?
A: The model number of this electric lifting platform is EW.
Q: Where is this electric lifting platform made?
A: This electric lifting platform is made in China.
Q: What certifications does this electric lifting platform have?
A: This electric lifting platform has CE, SGS, and BV certifications.
Q: What is the minimum order quantity for this electric lifting platform?
A: The minimum order quantity for this electric lifting platform is 1.
Q: Is the price of this electric lifting platform negotiable?
A: Yes, the price of this electric lifting platform is negotiable.
Q: What are the packaging details for this electric lifting platform?
A: The packaging details for this electric lifting platform are wooden case.
Q: What is the delivery time for this electric lifting platform?
A: The delivery time for this electric lifting platform is 30 work days.
Q: What are the payment terms for this electric lifting platform?
A: The payment terms for this electric lifting platform are T/T and L/C.
